Benefits of an Acetylene Torch

Posted on


An acetylene turbo torch is generally used for cutting metals. The oxy-fuel cutting process involves the combination of an oxygen source with a gas source, during which acetylene gas is used. Acetylene torches are also used for welding, which is why they are   sometimes also called welding torches. Acetylene is shipped in special containers for safety reasons, because if it becomes unstable it may explode, which may result in a disaster.

Acetylene Torch

An Acetylene Torch may be used for different purposes, such as cutting metals for fashionable art work or salvaging. Acetylene gas is generally manufactured by mixing calcium carbide with water. Calcium carbide is formed by mixing lime and coal, and heating it in a furnace at a temperature of around 2,000 degrees F. When acetylene and oxygen is mixed, a flame of 6,000 degrees F is produced, which can cut almost any type of metal.

The demand for acetylene welding equipment has increased a lot over the last couple of years. This is mainly because these torches are portable and less expensive. Acetylene torches are used in a variety of different industries, such as welding, pipe fitting and motorcycle building. Here are some other areas where these torches may be used.

  • Stone work : In this industry, an acetylene torch may be used for flaming. This involves using the torch to heat up the stone to a point where the top layer cracks, and then breaks. A steel brush is attached to the angle grind, which helps remove the first layer of stone.
  • Glass making : In the glass-making industry, an acetylene torch is used to produce a fire-polishing effect. It heats up the glass and generates a smooth appearance.
  • Jewelry : In the jewelry industry, an acetylene torch may be used for making fancy jewelry items, using a technique known as water welding.

Whenever you are working with an acetylene torch, you should always wear safety gear like goggles or a face-shield. You should also use welding gloves. Here is a list of basic equipment used by workers who operate acetylene torches.

Basic Equipment

  • Safety gear : Goggles or a face shield, as well as a pair of fire-resistant welding gloves are essential, before welding.
  • Pressure vessels : Two cylinders are needed, one filled with pressurized acetylene gas and the other filled with pressurized oxygen.
  • Hoses: Flame and oil resistant rubber hoses, rated for a working pressure of 200 PSI (pounds per square inch) are needed. These hoses are usually green in color for oxygen, and red in color for acetylene.
  • Gas pressure regulators : These regulators usually consist of two gauges, one for measuring high pressure (the gas in the cylinder), and the other for measuring low pressure (the gas emitted into the hose). The pressure in each cylinder is usually measured in PSIs, with the pressure flow adjusted using these regulators.
  • Flashback arrestors : A flashback occurs when a flame rapidly burns within the torch, and then passes back through the hose. This usually happens when the gases are not at the proper flow rates and are slower than the flame speed. Loose connections or leaks can also lead to flashbacks. Flashback arrestors cut off gas flow should a flashback occur, thus preventing damage to the torch or its operator. While arrestors are usually connected between the regulator outlet and the hose, they can also be connected between the hose and the torch.
  • Torch : The acetylene torch consists of a handle, mixing chamber, and valves to control the flow of oxygen and acetylene. A welding or cutting tip is attached to the end of the torch handle.
  • Striker : This is a metal instrument containing a piece of flint, which ignites the torch with a spark, when manually activated.

Operating an Acetylene Torch

Always inspect the equipment carefully before using. Make sure all components are connected correctly, and that there are no loose couplings or leaks. Also ensure flashback arrestors are in place, and the proper hoses and gauges are connected to the proper gas cylinders. Make sure the acetylene tank is kept at a constant pressure of 5 PSI. US regulations recommend keeping the acetylene tank pressure to below 15 PSI, and the oxygen pressure at 10 PSI.

Please remember to NEVER operate a welding torch without proper hands-on training from a professional. Once the equipment has been checked and the proper nozzle for cutting or welding has been attached, you are ready to start your job. The last step is opening the acetylene and oxygen valves, located on the tank and handle of the torch. You can easily tell them apart, because a cutting torch has three pipes that lie 90 degrees to the torch, and they also have an oxygen trigger.

A cutting torch can cut metal and steel. In the cutting process, a lot of heat is produced, during which other materials might catch fire or get melted. To cut a metal, you first have to heat it with the flame until it gets extremely hot and glows red. Once the material begins glowing, pull the oxygen blast trigger to mix the oxygen with the heated area. This results in the formation of iron oxide, which produces even more heat, thus completing the cutting process.

The acetylene flame can be adjusted, by either increasing or decreasing the oxygen supplied. A neutral flame is generally used while starting, which is later adjusted by the welder to suit his/her needs. An excess of acetylene can result in a carbonizing flame, which is characterized by three different colors, which results in different heat levels. This is usually observed when oxygen is first added to the flame. Basically, there are three different flame adjustments that can be made to the acetylene flame.

You can learn how to use an acetylene torch by taking classes, through an apprenticeship program, or through on-the-job training. One must definitely practice safety procedures whenever working with an acetylene cutting torch. They can be very dangerous, and training is certainly needed.

If you have any questions about this technology, which cutting torch would be right for you, contact any welding machine shop or dealer, who will explain things to you.
